EDC-communication module with LoRaWAN® or wireless M-Bus radio interface
The EDC-communication module (Electronic data capture module) with LoRaWAN® or wireless M-Bus interface is a clip-on module for secure remote reading to integrate water meters into LoRaWAN® or wireless M-Bus readout systems.
The Electronic Data Capture (EDC) module is designed for non reactive, electronic pulse detection of all the ZENNER water meters with modulator disc.
More information on the additional EDC module variant with M-Bus interface and electronic pulse output as an add-on module for water meters for remote reading or for integrating meters into wired M-Bus networks or readout systems can be found here.
Product images
Information
EDC-communication module with LoRaWAN® or wireless M-Bus radio interface
Downloads
Performance characteristics in overview
- Configurable radio technology (wM-Bus or LoRaWAN®)
- Battery powered
- Tampering detection
- Protection class IP68
- Retrofittable without destroying seals
- Flow direction recognition
- Secure data collection without the use of reed switches
- Optical interface for configuration purposes
The EDC module was developed for
- Single-jet dry dial meters ETKD / ETWD
- Multi-jet dry dial meters MTKD / MTWD
- Positive displacement meters RTKD
- Bulk meters WPD / WPHD / WSD / WPV
Smart Metering functions
- Self monitoring
- Tampering detection
- Dismounting of module and meter detection
- Reverse water flow detection
- Leakage detection
- Meter stop detection
- Meter oversized detection
- Meter undersized respectively pipe burst detection
Product options
| Communication Technologies |
|
